Waterman Industries Direct Drive Electric Deep Water Reel

For generations, Waterman Industries of Florida, Inc. has produced quality commercial fishing equipment targeting independent fishing fleets. At Waterman Industries, we stand for unmatched craftsmanship in every product produced.

Our gear box driven bottom reel avoids belt slippage under the most demanding conditions by using Waterman’s direct drive technology. The standard 3/4 hp motor is connected directly to the gearbox to provide superior torque for heavy loads. Additional fiberglass arms can easily be added for extra strength when fishing for heavier loads. The unit can be fitted with a 1 hp motor for additional power and torque.

The 3/4 hp and 1 hp continuous duty motors run at 1800 and 3350 rpm. At 3350 rpm the 25:1 gear box is turning the spool at 138 rpm.

The spool will take up 2 ft per rotation (approx.) with an empty spool; and, when full of line, they will take up (approx.) 3 ft of line per rotation. To find the spool rpm, divide the motor rpm by the rate of separation.
138 rpm, x 2 ft = 276 fpm, 138 rpm x 3 ft = 414 fpm

Spool capacity: 3500′ of 3/64″ stainless steel cable or 130# mono (1.2mm), 2500′ of 300# (1.8mm) mono, 900′ of 550# (2.5mm) mono or 700′ of 700# (3.0) mono. Green Stick Spool holds 5800′ of 700# (3.0mm) mono.

Note: Keep in mind these numbers are “no load”. The amount of weight being pulled will adjust the speed of retrieval. The heavier the catch, the higher the amp draw and the slower the speed. Most models can run continuously for about 60 minutes from “cold” (at the rated load), then continue at a 50 percent duty cycle.

WARNING,
Hi-Liner Fishing Gear and Tackle will not be responsible for motors that have water damage.
If the motor is exposed to the elements, IT IS IMPORTANT TO COMPLETELY SEAL THE MOTOR. Coating the motor casting with enamel paint and or trying to seal the motor with silicone sealant, only delays moisture and condensation from entering the motor cavity.
The best method, we have been told, is to apply silicone to the motor connections and using a two-part marine epoxy. Apply two or three heavy coats to the motor casing and or the gear box.
Waterman Industries recommends using a multi strand marine grade copper battery cable for wiring.
Use #4 battery cable if runs are less than ten feet. If longer than 10 feet, use #2 battery cable.
